The Link-Belt HTC-86100 is a 100-US-ton (85-metric-ton) telescopic boom truck crane offering versatile lift performance and modern operator aids. Equipped with a greaseless formed boom and on-board fly system, it delivers efficient hoisting and transport. Standard features include the Link-Belt Pulse operator interface, a 450-hp Cummins ISX12 diesel engine, and a compact under-96,000 lb transport weight with full counterweight.

Key Features:

• Telescopic boom extends from 38′ to 140′, offering broad working range and travel-ready stowed length.
• On-board two-piece bi-fold fly jib system (35′-58′) with optional extensions to ~90′, all stowable on the machine with no capacity deduction when stowed.
• Link-Belt Pulse operating system providing real-time boom angle, radius, load, and diagnostics via LCD interface.
• Powered by a 450 hp Cummins ISX12 diesel paired with a ZF TraXon (12-speed) transmission, supporting highway travel and jobsite mobility.
• Greaseless formed boom design reduces maintenance intervals and downtime for bossing and wear pad lubrication.

Safety Features:

• Integrated Rated Capacity Limiter (RCL) system with visual and audible warnings, along with anti-two-block and function-limiter safeguards.
• 360° continuous smooth hydraulic swing motor with spring-applied/hydraulic-released park brake and optional 360° positive swing lock for high-rise or urban lifts.
• Stow-n-Go outrigger pontoons that easily secure for transport or deployment, ensuring full stabilisation with minimal setup time.
• Boom floodlights, rear-side cameras and operator cab visibility enhancements to improve situational awareness during lifts and setup.
• Built-in diagnostics and telematics data-logging for proactive maintenance and fleet safety monitoring.

Transport Specifications:

• Fully equipped transport weight under approximately 96,000 lbs with 11,500 lb counterweight installed, enabling highway compliance in many jurisdictions.
• Carrier travel speed up to about 100 km/h (≈62 mph) enabling rapid repositioning between job sites.
• Compact transport dimensions including transport height around 11′-5″ and maneuverable wheelbase supporting urban and tight-site access.
• Full counterweight remains installed in transport position (up to 39,500 lbs in some configurations) to minimise assembly time on-site.
• Outriggers retract to a transport width of approximately 9′-8″ (centre-centre) enabling clearance through standard jobsite ingress and egress.
