The Kobelco CK1600G/CK1600G-II is a lattice boom hydraulic crawler crane with a lift capacity of 160 US tons. It features a 250 ft crane boom, going up to 350 ft with the combination of a fixed jib. The crane also has an optional auxiliary sheave extendable on booms of 50 through 240 feet.

The CK1600G is powered by a Tier IV Hino P11VC 363 engine, with 1084ft-s of torque. The “G” is for G-mode, Kobelco’s exclusive energy and fuel saving system. The G-Mode eliminates needless operations and engine functions, allowing for reduced fuel consumption, and saving up to 30% more fuel than competing cranes. This crane also features a patented diesel particulate filter (DPF) that significantly reduces the increased particulate matter and nitrous oxide making the CK1600G’s diesel engine one of the cleanest in the industry.

Console mounted controls allow for fine inching control of the rear drum and boom hoist. Free fall activation switches and drum indicators are built into the levers. The G-winch can produce maximum winch line speed at a low engine , allowing the line to be raised or lowered at maximum speed without raising the engine speed. The front, rear, and optional third drum are grooved for 26mm wire rope, and the rope capacity is 902 feet working length and 1148 feet storage length.

An independent two speed hydraulic propel drive is built into each crawler side frame. For added flexibility, crawler assemblies are designed with a quick disconnect feature for individual removal from axles. Each track on the CK1600G is made up of 48” wide crawler shoes.
