The Link‑Belt TCC‑750 is a telescopic‑boom crawler crane engineered for high reliability and efficient deployment in lifting operations. With a 75 USt class rating, it features a full‑power four‑section main boom, robust Tier 4F six‑cylinder engine, and advanced control electronics. The design emphasises compact transportability, quick setup, and strong boom performance — providing contractors with a flexible crane that excels in building, infrastructure and heavy‑lift applications.

Key Features:

• Four‑section formed steel main boom offering extended reach in two telescoping modes.
• Cummins QSB 6.7L engine rated at 215 hp, meeting Tier 4F emissions.
• “Link‑Belt Pulse” integrated crane operating system with real‑time load/radius display and data logging.
• Full hydraulic pilot controls for smooth boom extension/retraction and precise operation.
• Compact transport configuration designed to ship in one or two loads, reducing mobilisation time.

Safety Features:

• Rated capacity limiter (RCL) system alerts operator of boom length, angle and percentage of rated load.
• Steel‑cab operator enclosure with tinted/tempered safety glass, vibration isolation and climate control.
• Swing park brake and house‑lock system for secure boom position during transport and non‑operation.
• Hydraulic holding valves on boom cylinders to prevent uncontrolled movement of telescoping sections.
• Self‑cleaning sealed track rollers and wide track shoes for reduced ground pressure and improved stability on rough surfaces.

Transport Specifications:

• Designed to transport in one or two loads thanks to modular carbody, counterweight and boom section construction.
• Retractable side frames, hydraulically adjustable track gauge for reduced width during travel.
• Low tailswing radius allows simpler placement on transport trailers.
• Transport length approximately 49 ft and width about 17 ft in compact configuration.
• Boom sections and counterweight designed to ship efficiently; quick staging minimises on‑site assembly time.
